The "Scout" Dump Body
Please call or e-mail for more
information and pricing!
(866) 433-2075
sales@martintruckent.com
Ranger Dump Body Specifications
  • 8 Yd to 15 Yd.
  • Length - 13' to 16'
  • Width - 88" (inside)
  • Sides - 30" & 36"
  • Head - 50"
  • Tail Gate - 44" & 50"
  • Top Hinge - Grease Fittings
  • Floor to Wall Radius - 6" Beveled
  • Deluxe Dual Pedestal Controls
  • Air Control Tail Gate Kit
  • Sloping Rub Rails - 45 degrees
  • 10 ga. Hi-Tensile Sides & Ends
  • 7 ga. Hi Tensile Floor
  • Rear Posts - 4" x 12" Full Depth
  • Double Acting Tail Gate - 4 Way
  • 1 1/4" Upper Tail Gate Hardware
  • Tail Gate Pins - Upper 1 1/2" and Lower 1 1/4"
  • 5/16" Spreader Chains
  • Fully Primed
  • Back Up Alarm
  • 8" - 15# Wide Flange Beam Long sills
  • Side Mount Tank - 30 Gal
  • Grommeted and Sealed Stop, Turn & Tail
    Light in Rear Post
  • Clearance/Reflector Lights on each Side
Dump Body Specifications
  • 8 Yd. to 17 Yd. - Water Level
  • Length - 12' to 18'
  • Width - 88" (Inside), 96" (Outside)
  • Sides - 30", 36", and 42"
  • Head - 50"
  • Tail Gate - 38", 44", and 50"
  • Top Hinge - Grease Fittings
  • Floor to Wall Radius - 8" Bevi Round
  • 7" Channel Long Sills
  • 4" Channel Cross Members - 12" Centers
  • Sloping Rub Rails - 45 degrees
  • 10 ga. Hi-Tensile - Sides & Floor (1 piece)
  • Top Rail - 3" x 4" Rec. Tubing
  • Rear Posts - 4" x 12" Full Depth
  • Double Acting Tail Gate - 4 Way
  • 1 1/4" Upper Tail Gate Hardware
  • Tail Gate Pins - Upper & Lower - 1 1/2"
  • Tail Gate Cross Shaft - 1 1/2"
  • 5/16" Spreader Chains
  • Fully Primed
  • Horizontal or Vertical Side Bracing and
    Tailgate Bracing
  • All Rubber Grommeted Lights
  • Front Corner Posts
  • Deluxe Dual Pedestal Controls
  • Dual Safety Props
Dump Body & Hoist Options
  • 7 ga., 1/4" and T-1 Floors
  • 6 or 9 Panel Tail Gate Bracing
  • Spreader Apron
  • Air Control Tail Gate Kit
  • Side Boards
  • Ladders
  • Ditch Gates
  • Tapered Rear Post - 15 degrees
  • Tapered Sides (42" to 30")
  • Rebar Walk Rails
  • 1/4, 1/2, & Full Cab Shields
Mabar Dump Beds
Ranger Dump Body &  Hoist Options
  • 1/4 & 1/2 & Full Cab Shield
  • Criss-Cross Tail Gate Bracing
  • Spreader Aprons
  • Sloped Sides
  • Tapered Rear Gate
  • T-1 Floors
  • Tapered Rear Post
  • Rebar Walk Rails
  • Chute Gate
  • Side Boards
Ranger Package Dump Bodies
"Scout" Dump Body Specifications
  • 3 yd. to 8 yd. - Water Level
  • Length - 9' and 10'
  • Width - 87" (Inside), 96" (Outside)
  • Sides - 18", 24", 30" and 36"
  • Head - 34", 38", and 44"
  • Tail Gate - 26", 32", 38", and 44"
  • Top Hinge - Grease Fittings in top ear
  • Floor to Wall Radius - 2 1/2"
  • 5" Channel Long Sills
  • 3" Channel Crossmembers
  • Sloping Rub Rails - 45 degrees
  • 10 ga. Hi-Tensile Steel
  • Top Rail - 4" Wide
  • Rear Posts - 4" x 12" Full Depth
  • Double Acting Tail Gate - 4 Way
  • 3/4" Upper Tail Gate Hardware
  • Tail Gate Pins - Upper 1 1/4" and Lower 1 1/4"
  • Self Aligning Upper Tailgate Hardware
  • 5/16" Spreader Chains - Gr. 43
  • Fully Primed
  • Over-Center Tailgate Latch
  • 1 piece floor
  • Crossmembers on 16" Centers
  • Grommeted Sealed Clearance Lights with Reflectorized Lens
"Scout" Dump Body Options
  • 7 ga. Floor and/or Tailgate
  • Spreader Aprons
  • Criss-Cross Tail Gate Bracing
  • Horizontal Side Bracing
  • Air Control Tail Gate
  • Cab Shields
All Steel Dump Bodies
